Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 085501 |
| Body Style | Cylindrical |
| Connection Type | M12 4-Pin |
| Current Consumption | 15 mA (Max.) |
| Current, Switching | 200 mA |
| Dimensions | 65mm L |
| Frequency, Switching | 0.8 kHz |
| Housing Material | Nickel Plated Brass |
| IP Rating | IP67 |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 8 mm |
| Minimum Operating Temperature | -25 C |
| Mounting Type | Flush |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -25 C |
| Output | PNP-NO |
| Primary Type | Inductive Proximity Sensors |
| Series | |
| Shielding | Shielded |
| Standards | cULus Listed, cCSAus Certified, CE Marked |
| Supply Voltage | 10-30 VDC |
| Termination | 3-wire |
| Voltage Regulation | DC |
Overview
P F developed the first inductive proximity sensor in 1958. Since then, we've become the world's largest manufacturer of inductive proximity sensors with over 5,000 active models in our current production. Features:
