Product Details
＋
Specifications
- Projection System RGB liquid crystal shutter projection system
- Projection Method Direct Mounting, Lighting Track (requires
- Lighting Track option), Floor Standing (requires Floor Stand
- option)
- Driving Method Poly-silicon TFT Active Matrix
- Pixel Number 1,024,000 dots (1280 x 800) x 3
- Color Brightness3 Color Light Output: 2,200 lumens
- White Brightness3 White Light Output: 2,200 lumens
- Aspect Ratio 16:10 widescreen
- Native Resolution WXGA (1280 x 800)
- Light Source Laser Diode
- Laser Life1
- Normal Mode: Up to 20,000 hours
- Extended Mode: Up to 30,000 hours
- Throw Ratio Range 1.38 (Zoom: Wide), 2.19 (Zoom: Tele)
- Size (Projected Distance)
- 30" – 150" [0.88 – 4.51 m] (Zoom: Wide)
- Keystone Correction Manual Vertical: ± 45 degrees;
- Horizontal: ± 40 degrees
- Dynamic Contrast Ratio Up to 2,500,000:1
- Color Reproduction Up to 16.7 million colors
- Project From Nearly Any Angle
- Movement: Left/Right: 180 degrees, Up/Down: 180 degrees;
- Ball-joint Axis Rotation: 360 degrees
- Track Compatibility
- Halo: TEK441, 442, 443
- Juno: TEK44FT(Black/White)
- Global Trac: TEK44-1, 44-2, 44-3
- Type Optical zoom (Powered)/Focus (Powered)
- F-number 1.51 – 1.92
- Focal Length 18.2 – 28.4 mm
- Zoom Ratio 1 – 2.21 (Total), (Optical zoom: 1 – 1.58, Digital
- zoom: 1 – 1.4)
